| Weight | 8 kg |
|---|---|
| Dimensions | 40 × 30 × 40 cm |
| sphere | 0~±25D(0.01/0.12/0.25D steps) |
| Cylinder | 0~±9.99D(0.01/0.12/0.25D steps) |
| Axis | 0~180°(1°step) |
| Addition | 0~±9.99D(0.01/0.12/0.25D Steps) |
| Prism | 0~15(0.01/0.12/0.25ΔSteps) |
| Measurement Mode | Lens auto-recognition |
| Measuring mode | Contact lens |
| Pupil distance | 45~90mm,0.25mm steps |
| Cylinder | +,+/-,- |
| Prism | X-Y, P-B |
| Measuring speed | 0.1 second |
| Lens diameter | Φ20~108mm |
| Contact lens | Soft/hard lens |
| ABBE | 30-60 |
| Display | 5.6″LCD/TFT |
| Thermal Printer | |
| Power Supply | 100~240v, 50/60Hz |
| Dimension | 222*161*372mm |
| package | 530*330*370mm |
| Weight | Approx 5KG |
